M8M5 KIT Instructions
NOTE: follow this step only if your TV/monitor has M8 holes which need
to be reduced to M5 or for Samsung models using the holder ring.
Install M8M5 reducer bushing to TV/Monitor and use M5 x 20 mm
monitor screws to secure when using the Samsung holder ring.
M5x20mm
Monitor Screw
8
Attach top and bottom bracket covers
16 of 21
TV / Monitor Mounting
M8 size hole
M8M5 Reducer
Bushing
Holder Ring
(Not Included * Samsung Only)
888-45-281-W-01 rev. J • 09/19
