Mount arm to wall bracket.
b
a
10 of 21
NOTE: when
sliding
sleeve on
to bracket,
align slot
over rota-
tion stop.
c
Top View
Rotation
Stop on
Bracket
M6
M6 x 45mm
4mm
+ =
Slot
Sleeve on
in
Bracket
Seeve
