RULES FOR SAFE DRIVING
For the safety of the child, before starting up the
vehicle read and carefully follow the following
instructions.
• Teach the child how to use the vehicle properly for
safe and enjoyable driving.
• Before starting, check that there are no people or
objects obstructing the vehicle's path.
• Drive with hands on the handlebars/steering wheel
and always watch the road ahead.
• Brake in good time to avoid collisions.
2nd GEAR (if present)
Initially, use in 1st gear is recommended. Before
enabling 2nd gear, check that the child has learned to
use the handlebars/steering wheel, 1st gear and the
brake correctly, and has become familiar with the
vehicle.
WARNING!
• Check that all the wheel fixing studs/nuts are
fastened properly.
• If the vehicle is overloaded, as can happen on soft
sand, mud, or very uneven ground, the overload
switch will immediately disconnect the power. The
power supply will be restored after a few seconds.
• Only for 12 and 24 Volt vehicles: in first gear the
vehicle has a differential effect like a real motor
vehicle; on smooth terrain and with just one child
on board, the two wheels can turn at different
speeds and they can slip and slow down.
UNINTERRUPTED FUN: Keep a spare set of charged
batteries ready for use.
PROBLEMS?
THE VEHICLE DOES NOT WORK?
• Check that there are no disconnected cables under
the accelerator plate.
• Check the operation of the accelerator button and
replace it if necessary.
• Check that the battery is connected to the
electrical system.
THE VEHICLE LACKS POWER?
• Charge the batteries. If after charging the problem
persists, have the battery and charger checked by
an assistance centre.
ASSISTANCE SERVICE
offers an after-sales assistance service,
PEG PEREGO
directly or through a network of authorized
assistance centres, for any repairs or replacements
and the sale of original spare parts. To contact the
assistance centres refer to the "Assistance Centres"
booklet included in the packaging.
Peg Perego always strive to best satisfy their
customers' needs. Knowing the opinions of our
customers is therefore very important and valuable
to us. We would be very grateful if, once you have
used the product, you would fill out the
which you can find on
SATISFACTION QUESTIONNAIRE
the internet at: www.pegperego.com, making
any observations or suggestions you might have.
ASSEMBLY INSTRUCTIONS
WARNING
ASSEMBLY MUST ONLY BE CARRIED OUT BY
ADULTS. TAKE CARE WHEN REMOVING THE
VEHICLE FROM ITS PACKAGING. ALL THE
SCREWS AND SMALL PARTS ARE CONTAINED IN
A BAG INSIDE THE PACKAGING. THE BATTERY
MAY ALREADY BE FITTED INSIDE THE ITEM.
1 • Warning: ensure that the front fork bolts are well
tightened.
2 • Put the handlebar in place.
3 • Place the handlebar fastener plate as shown in
the figure.
4 • Screw the 3 screws.
5 • Place the dash between the two tabs on the grill.
6 • Fasten the dash into place using the two screws
that come with the vehicle.
7 • Stick the mirrors into their holes on the
handlebars and turn them outwards to fasten
them into place.
8 • Connect the throttle handle to the installation.
9 • Insert the cable into the crack.
10 • Place the windscreen on the grill.
11 • Screw.
12 • Put the arrow in place.
13 • Place the screws.
14 • Place the grill on the frame and snap it into
place, making sure to fasten all three hooks.
15 • Snap the license plate into place.
16 • Snap the taillight into place.
17 •18 • Position the luggage carrier and fasten it
using the four screws.
19 • Using the tool supplied, unscrew the nuts located
each side of the side rear wheel axle.
20 • Remove the struts.
21 • Fit the stabiliser wheels.
22 • Place the washers and then the nuts as shown in
the drawing.
23 • Tighten. Warning: when yuo remove the stabiliser
remember to reinsert the spaces.
24 • Loosen the screws on the seat.
25 • Raise the saddle by pushing forward on both
sides. Caution: always reclose and re-screw the
saddle after doing anything inside the battery
compartment.
26 • Connect the two plugs and close the saddle back
down. The vehicle is ready for use.
FEATURES AND USE OF THE VEHICLE
27 • A:
HAND THROTTLE
to start the vehicle.
• B: horn button.
28 • C: . The vehicle stops when the brake
BRAKE
pedals is pressed.
29 • Use when the motorbike is not fitted
STAND:
with stabilizers.
30 • : unscrew and lift off the cap of the
2nd SPEED
petrol tank;
31 • Press the button and select the 2nd speed
setting. Close by screwing the cap back on.
REPLACING THE BATTERY
32 • Remove the screw and raise the saddle by
pushing forward on both sides.
33 • Unplug the plug.
34 • Unscrew the battery fastener.
35 • Replace the battery. Install the battery fastener
and secure it into position using the two screw.
Connect the two plug and close the saddle back
down.
CHARGING THE BATTERY
WARNING: BATTERY CHARGING AND ANY
OTHER WORK ON THE ELECTRICAL SYSTEM
MUST BE CARRIED OUT BY ADULTS.
THE BATTERY CAN ALSO BE CHARGED
WITHOUT REMOVING IT FROM THE TOY.
36 • Unplug vehicle wiring terminal A from battery
terminal B, by pressing terminals on side and
pulling apart.
37 • Plug the battery charger terminal to a wall outlet
following the instructions enclosed. Connect the
plug B to the battery charger plug C.
38 • Once the charge is completed unplug recharger
from wall outlet. Unplug recharger cord terminal
C from battery terminal B.
39 • Plug battery terminal A into vehicle wiring
terminal B. Close saddle.
CONSUMER
ASSEMBLY
. Turn the knob downwards
