General use

The Levenhuk LabZZ M101 microscope is safe for health, life and property of the consumer and the environment when
properly used, and meets the requirements of international standards. The microscope is designed for observing
transparent objects in the transmitted light using the bright field method. May be used by kids over 5 years old.
The package includes a Levenhuk K50 experiment kit that has everything you need to prepare microscope slides
yourself. The detailed guide will teach you how to properly prepare secimens and conduct amazing experiments.
Caution: Children should use the microscope under an adult's supervision only.
The package includes:
• Microscope
• Objectives: 4х, 10х and 40х
• Eyepiece: WF10х–WF16x
• Stage with specimen holders
• Diaphragm disk
The Levenhuk K50 experiment kit includes:
• "Attractive Microscope. Scrutinizing
the Microcosm" User Guide
• Forceps
• Hatchery for Artemia (brine shrimp)
• Microtome
• Flask with yeast
• Flask with glue
Microscope parts
Base.
It supports the weight of the microscope and houses the illumination source, electronics and control
mechanisms.
Eyepiece tube.
Combines the eyepiece with the objectives system. Holds the eyepiece, Barlow lens (below the
eyepiece) or a digital camera (in place of eyepiece). A Barlow lens and a digital camera are not included in the kit.
Eyepiece and objective.
multiplying the eyepiece magnification to the objective magnification.
Revolving nosepiece.
This triple nosepiece with 3 pre-installed objectives allows you to change objectives smoothly
and easily.
Stage.
Sturdy and reliable stage with two specimen holders can be used to move your slides while observing them.
The lower illumination light passes through the opening in the middle of the stage.
Diaphragm disk.
Is located below the stage and has apertures of various diameter to adjust the passing light rays.
Rotate the disk to select the desired aperture.
Focusing knob.
A coarse focusing system allows moving the stage up and down adjusting the sharpness of the
specimen image.
Upper illumination.
LED illumination with adjustable brightness can be powered by 2 AA batteries. The lower
illuminations is used to observe transparent objects. Using a supplemental light source, such as a table lamp, directed
at the specimen will enable you to observe less transparent objects.

Using the microscope

Getting started
• Unpack the microscope and make sure all parts are available.
• Move the stage to the lowermost position using the focusing knob.
• Make sure the batteries are correctly installed in the battery compartment; insert new batteries if required.
• Insert the eyepiece into the eyepiece tube.
• Slowly adjust the illumination brightness, from dark to light.
Focusing
• Place a specimen on the stage and fix it with the holders.
• Select the 4x objective rotating the revolving nosepiece.
• Move the specimen to place its thickest part exactly under the objective.
• Rotate the focusing knob to slowly raise the stage until the objective is close to the specimen; keep checking the
distance between the objective and the object to avoid their contact.
CAUTION: The objective should not touch the specimen, otherwise the objective or/and the specimen might be
damaged.
Consist of lenses that allow magnifying the image. The total magnification is calculated by
• Built-in lower LED illumination
• 2*AA batteries
• Levenhuk K50 experiment kit
• User manual and warranty
• Flask with sea salt
• Flask with brine shrimp
• Blank glass slides (5 pieces)
• 5 samples (fly's limb, onion, cotton stem,
slice of a tree trunk, pine)
• Pipette
• Dust cover
3
EN
