Installation

Caution!
The DIP switches in public thermostat
T-163 must be set before the thermostat is
registered.
Caution!
The DIP switch in the public thermostat T-163
must be set to one of the available functions,
otherwise it cannot be registered.
Caution!
Do not attempt to connect Uponor Smatrix
Base thermostats to the controller. They are
not suited for each other, and they may get
damaged.
N O T E !
If the outdoor sensor is placed to far
away from the reference room, a separate
thermostat can be used to register the
outdoor sensor.
A. Attach the controller to the wall by using wall
screws and plugs.
If the controller is installed inside a metal cabinet,
then locate the antenna outside the cabinet.
B. Connect the antenna to the controller (1), and
attach it to the wall using a wall screw and plug (2)
or the adhesive strip (3).
C. Connect additional equipment, such as actuator(s),
circulation pump(s), temperature sensors etc, and
secure them with cable clamps.
The outdoor temperature sensor can be connected
to either the controller or a thermostat.
D. Insert batteries into the thermostats.
E. Connect optional external sensor.
F. Set the DIP switch on public thermostat T-163.
1
Function
Used as a room thermostat
Off
Used as a room thermostat
together with an outdoor Off
temperature sensor
Use a remote sensor
Off
U P O N O R S M AT R I X M O V E P L U S · Q U I C K G U I D E
Q U I C K G U I D E
Switch
2 3 4
Off Off Off
On Off Off
On Off On
G. Check that all wiring is complete and correct:
• Actuator(s)
• Heating/cooling switch
• Circulation pump(s)
• Temperature sensor(s)
H. Ensure that the 230 V AC compartment of the
controller is closed and the fi xing screw is tightened.
I. Connect the power cable to a 230 V AC wall socket,
or if required by local regulations, to a junction box.
J. Set time and date on thermostats (digital
thermostat T-168 only).
K. Select thermostat control mode (settings menu 04,
in digital thermostats only). Default: RT (standard
room thermostat).
RT = Room temperature
RFT = Room temperature with external fl oor sensor
(limitations does not affect the operation
of the Move PLUS controller, when not
integrated to a Wave/Wave PLUS/Space/
Space PLUS controller)
RS = Remote sensor
RO = Room temperature with remote outdoor
sensor
L. Register the thermostat and outdoor sensor (see
next page).
M. Setup the system (see page 10).
