CLASSE CA-201 Bedienungsanleitung Seite 3

Figure 3 – Jumper settings
J3 J2 J1
X X X
X X X
X X Out
X X Out
X Out X
X Out X
X Out Out
X Out Out
Out X X
Out X X
Out X Out
Out X Out
Out Out X
Out Out X
Out Out Out
Out Out Out
J0 ADDRESS RC Button
X 0 Amp 1
Out 1 Amp 2
X 2 Amp 3
Out 3 Amp 4
X 4 Amp 5
Out 5 Amp 6
X 0 Amp 1
Out 0 Amp 1
X 0 DC
Out 1 DC
X 2 DC
Out 3 DC
X 4 DC
Out 5 DC
X 0 DC
Out 0 DC
Auto ON Note
No QC setting
No
No
No
No
No
No
Yes Turn on when AC is live
No DC level: 5v=on, 0=off
No
No
No
No
No
No
Yes ON as plug in
