I/O Panel
1
17
No. Description
1 USB 2.0 Ports (USB_1_2)*
2 D-Sub Port
USB 3.0 Ports (USB3_34)
3
(AMD A88X (Bolton-D4))
4 eSATA Connector
5 LAN RJ-45 Port**
6 Central / Bass (Orange)
7 Rear Speaker (Black)
8 Line In (Light Blue)
9 Front Speaker (Lime)***
4
2 3
16 15
4 5
14 13 12
No. Description
10 Microphone (Pink)
11 Optical SPDIF Out Port
USB 3.0 Ports (USB_78)
12
(Etron EJ188)
USB 3.0 Ports (USB_5_6)
13
(Etron EJ188)
14 Clear CMOS Button
15 HDMI Port
16 DVI-D Port
17 PS/2 Mouse/Keyboard Port
6 8
7 9
11 10
