Geami WrapPak HV

3. OPERATOR INSTRUCTIONS

EN
Before operating the converter, the
information from
be read and understood.
Warning!
3.1

Construction and Control

• 1 foot switch
• 1 On/Off power switch (backside)
• 1 On/Off main switch (front)
• 1 line power fuses
3.2

Turning the Converter On

First, check that the following conditions are met:
• The power cable is plugged into the converter.
• The power switch next to the power cable is set to "I"
• The foot switch is plugged in
• All covers are closed
• Hands are free from the converter exit chute
Then follow these steps:
• Plug the power plug into the wall socket with ground
contact
• Set the main switch to "I"
The converter is now ready for use.
3.3

Loading the Paper

Pay attention when using hand tools
such as knives, scissors etc, due to the
risk of cutting!
Warning!
Pay attention to ergonomic factors such
as lifting, bending, reaching, etc.!
Warning!
To load paper rolls in the converter, complete the following
steps:
1.
Turn the speed control down to a slow speed.
2.
Place a roll of die-cut paper on the top back paper
support bracket so that the bottom of the roll unwinds
towards the machine. Caution: Mind your hands, risk to
pinch,
3
®
Section "Safety" must
3.
Fold each corner down towards the centre, forming an
arrow
4. Insert the paper into the rear slot
5.
Press the foot switch until the paper comes through the
front rollers.
6.
Manually pull die-cut paper towards you untill it expands
to its maximum.
7.
Place a roll of interleaf paper on the top front paper
support bracket so that the bottom of the roll unwinds
towards the machine. Caution: Mind your hands, risk to
pinch,
8.
Insert the interleaf into the top front slot
