CAME RODEO Bedienungsanleitung Seite 39

DIAGRAMS
DOOR WING(S) WITH
FRAME, WITHOUT LOWER
GUIDE PROFILE
L
OF DOOR
L
MA 7351 = L 1000 mm
MA 7451 = L 1500 mm
MA 7551 = L 2000 mm
WINGS WITH
DOOR WING(S) WITH
FRAME, WITH LOWER
GUIDE PROFILE
MA 7371 = L 1000 mm
MA 7471= L 1500 mm
MA 7571 = L 2000 mm
FRAME
MA 7371= L 1000 mm
MA 7471= L 1500 mm
MA 7571= L 2000 mm
RODEO
SERIE
7
