14. Main Technical Data

Dimensions - Weight 20 cm x 17.5 cm x 7 cm (package) - 700g
Display 3.5'' color LCD
Power supply Lithium ion battery 3.7V, 1600mAh
Charger AC 100-240V - 50/60Hz - 5.5VA
Power rating 0.3 W
Degree of protection IPX 0
Electrical safety class - Applied part Class II - BF
Operating conditions Indoor use only - 10°C / 40 °C - Relative humidity <80% non-condensing at 0° - Altitude <
2000 m above sea level
Transport and storage conditions -20 °C / +50 °C - Relative humidity 20% - 80%, non-condensing at > 40 °C - Atmospheric
pressure 50 kPa - 106 kPa
15. Electromagnetic Compatibility (EMC) – Declaration of conformity
Guidance and manufacturer's declaration
Dual Pex is intended for use in the electromagnetic environment specified below. The customer or the user of Dual Pex shall make sure it is
used in such an environment.
Electromagnetic emission
Emissions test
RF emissions - CISPR 11
RF emissions - CISPR 11
Harmonic emissions IEC61000-3-2
Voltage fluctuations/flicker emissions - IEC61000-3-3
6
Processing Warning
Steam sterilization at 135°C at least Use only approved autoclave devices
4 minutes, or at 121°C at least 35 according to EN 13060 or EN 285.
minutes. The sterilization procedure must comply
Minimum drying time after sterilization: with ISO 17665.
10 minutes. Waiting for cooling before touching.
Keep the components in sterilization Check the packaging before using it
packaging in a dry and clean (packaging integrity, no humidity and
environment. validity period), otherwise sterilize again.
Compliance Electromagnetic environment - Guidance
Group 1 Dual Pex uses RF energy only for its internal function.
Therefore, its RF emissions are very low and are not likely to
cause any interference in nearby electronic equipment.
Class B Dual Pex is suitable for use in all establishments, including
domestic establishments and those directly connected to
Not applicable
the public low-voltage power supply network that supplies
Not applicable
buildings used for domestic purposes.
Electromagnetic immunity
Immunity test IEC 60601 test level
Electrostatic discharge (ESD) ±6 kV contact
IEC 61000-4-2 ±8 kV air
Electrical fast transients/bursts ±2 kV for power supply lines
IEC 61000-4-4 ±1 kV for input/output lines
Surge ±1 kV line(s) to line(s)
IEC 61000-4-5 ±2 kV line(s) to earth
Voltage dips, short interruptions <5% UT (>95% dip in UT) for 0.5 cycle
and voltage variations on power 40% UT (60% dip in UT) for 5 cycles
supply lines - IEC 61000-4-11 70% UT (30% dip in UT) for 25 cycles
<5% UT (>95% dip in UT) for 5s
Power frequency (50/60 Hz) 3 A/m
magnetic field IEC 61000-4-8
U is the AC mains voltage prior to application of the test level. EUT is the Unit Under Test
T
Immunity test IEC 60601 test level Compliance level Electromagnetic environment - guidance
Conducted RF - 3 Vrms 3Vw
IEC 61000-4-6 150 kHz to 80 MHz
Radiated RF - 3 V/m 3.5 V/m
IEC 61000-4-3 80 MHz to 2.5 GHz
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected be absorption and
reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for ratio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicated theoretically with
accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey
should be considered. If the measured field strength in the location in which Dual Pex is used exceeds the applicable RF
Compliance level Electromagnetic environment -
guidance
±2, 4, 6 kV contact Floors should be in wood, concrete or
±2, 4, 8 kV air ceramic tile. If covered by synthetic
material, the relative humidity should
be at least 30 %.
Not applicable The test is applicable since the EUT
Not applicable does not have AC/DC power plugs
and signal / interconnecting cable
longer than 3m.
Not applicable The test is not applicable since the
Not applicable EUT does not have AC power plug.
Not applicable The test is not applicable since the
Not applicable EUT does not have AC power plug.
Not applicable
Not applicable
3 A/m Power frequency magnetic field
should be at levels characteristic
of a typical location in a typical
commercial or hospital environment.
Portable and mobile RF communications equipment should be used no
closer to any part of Dual Pex, including cables, than the recommended
separation distance calculated from the equation applicable to the frequency
of the transmitter.
Recommended separation distance
d=1.2√
P
d=1.2√ 800 MHz ~ 800 MHz
P
d=2.3√ 800 MHz ~ 2.5 GHz
P
Where P is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer and d is the recommended separation
distance in meters (m). Field strengths from fixed RF transmitters, as determined
by an electromagnetic site survey, should be less than the compliance level in
each frequency range.**
Interference may occur in the vicinity of equipment marked with the following
symbol:
