Specifications
Monitor
Specifications
Picture Tube
Viewable Image Size:
Input Signal
Display Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and vertical
frequencies only
Active Display Area
(Factory setting)
Active Display Area
(Full scan)
Power Supply
Current Rating
Dimensions
Weight
Enviromental Considerations
Operating Temperature:
Storrage Temperature:
NOTE: Technical specifications are subject to change without notice.
MultiSync FE700
Monitor
Diagonal: 43 cm (17 inch)
41 cm (16 inch)
Radius: 50.000 mm
ANALOG 0,7 Vp-p/75 Ω
Video:
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Analog input: Unlimited number of Colors
Horizontal: 31 kHz to 70 kHz
Vertical: 55 Hz to 120 Hz
640 x 480 @ 60 to 120 Hz
800 x 600 @ 55 to 110 Hz
832 x 624 @ 55 to 105 Hz
1024 x 768 @ 55 to 87 Hz . . . . . . . . . . . . . . . . . . .
1152 x 870 @ 55 to 77 Hz
1280 x 1024 @ 55 to 66 Hz
Horizontal: 315 mm
Vertical: 236 mm
325 mm
243 mm
AC 100-120 V / 220-240 V, 50/60 Hz
1,8 A @ 100-120 V / 1,0 A @ 220-240 V
403 (W) x 427 (H) x 424 (D) mm
19,0 kg
+10° C to +35° C
Humidity: 30% to 80%
Altitude: 0 to 3.000 m
-20° C to +60° C
Humidity: 10% to 90%
Altitude: 0 to 13.700 m
Notes
90° deflection, 0,25 mm grille pitch, medium short
persistence phosphor, aperture grille CRT,
multi-layered, anti-staticscreen coating, dark-tint
screen and OptiClear screen.
Depends on the display card
Automatically
Automatically
Some systems may not support all modes listed
NEC cites recommended resolution at 85 Hz for
optimal display performance.
Dependent upon signal timing used, and does not
include border area.
Dependent upon signal timing used, and does not
include border area.
E - 11
