IV. GETTING STARTED
Warning! The blower must NOT be used or switched on until it has been fully assembled.
WARNING: IF ANY PART IS MISSING OR DAMAGED, DO NOT OPERATE THE
MACHINE UNTIL YOU HAVE REPLACED THE MISSING OR DAMAGED PART.
4.1- Unpacking
- Remove product from its packaging.
- Check that tool and accessories are not damaged.
4.2- Assembly
The tool requires some assembly prior to first time use.
Tubes assembly (Fig.2)
Insert lower tube (2) into upper tube (4) and lock with lock/release tab (3).
Insert upper tube (4) into housing section (a) and lock with lock/release tab (5).
Check that tubes assembly is correctly done and securely locked.
4.3- Battery
NOTE: The battery is provided with a low charge state. To ensure proper operation of the tool, fully
recharge the battery before first use.
Tips to ensure optimal battery life
- Do not to drop, hit, or damage the battery.
- Recharge the battery before it is completely drained.
When you notice that the tool performance is decreasing, recharge the battery accordingly.
- Never charge a fully charged battery. Overloading reduces its life.
- If the battery is hot, allow it to cool down before proceeding with charging.
- When the product is not used, it is recommended to charge the battery every 3 months.
To insert and remove the battery
- To insert the battery: insert the battery into the handle housing. Make sure it is properly locked.
- To remove the battery: press the release button then pull the battery to remove it from the handle.
Charging the battery
- Place the charger on a flat, dry surface within one meter of a power outlet.
- Remove the battery from the tool.
- Insert the battery into the charger. (Only recharge with the supplied charger).
- Connect the charger to a suitable power source.
- Charge 20V 2.0Ah battery for 5-7 hours.
- After charging, remove the battery from the charger and install it back on the tool.
- Unplug the charger from the power source and store it.
Note: keep the charger and the battery at a temperature between +10°C and +40°C.
4.4- Starting the machine (Fig.1)
- Switching on: push forward the switch (6) to position "I".
- Switching off: pull back the switch (6) to position "0".
Page 26 / 75
