Product installation

1) Connect the power cable to the cigarette lighter. ensure the cable is placed around the windscreen so as not to
obstruct the driver's view and then fix it securely in place. attach thedevice between the glass and the mirror.
This will give you the optimal picture.
2) Do not install in a position which obstructs the driver's view or distracts them.
3) some vehicles continue to supply power to the cigarette lighter, even when the engine is turned off. In this
case, before leaving the vehicle, unplug the cable from the cigarette lighter.
4) When using the device for the first time, the battery may be low. If you cannot switch on the device due to low
power, manually connect the external power cable to charge the battery.
5) Use only a high-quality micro sDHC card of class 10 or higher. For optimal recording use, we recommend cards
with a capacity of at least 8GB up to a maximum of 32GB. If this is the first use of the card, we recommend
formatting it first.

Quick functions

1) leD light – tap the UP arrow to switch between On/OFF/auto.
2) Parking mode – tap the „ParKInG mODe" button.
3) On/OFF lCD – tap the DOWn arrow.
4) lock/unlock file – file can be lock/unlock during recording by tap mODe button.
5) Timelapse – for On/OFF timelapse pushand hold red button (P) at least for two seconds.

Icons annotation

DISPLAy
mem card not detected
mem card detected
Battery status
Video mode
Photo mode
Video resolution
File locked
DISPLAy: White Balance
White Balance – auto
White Balance – Daylight
White Balance – Cloudy
leD light OFF
leD light On
leD light auto
exposure Value
motion Detection
Parking mode
Timelapse
White Balance – Fluorescent
White Balance – Tungsten
