Parts List / Option Parts List
Ersatzteileliste / Tuningteileliste
Parts List
En
Parts # Qty
Description
1504
1
GLOW PLUG COLD R5
3847
1
TE 37 WHEEL 26mm CHROME 6mm OFFSET
4402
1
SUPER DRIFT TIRE 26mm RADIAL (TYPE A)
6122
10
BODY PIN (MEDIUM)
6132
20
PLASTIC STRAP (SMALL/BLACK)
6154
10
NYLON STRAP (3.5x150mm/BLACK)
6163
5
SERVO TAPE 20x100mm
6274
1
PRECUT FOAM BUMPER GRAY (RS4)
SHOCK SHAFT 3x31mm
6807
2
6816
6
SILICONE O-RING S10
6819
5
SILICONE O-RING P-3 (RED)
6823
5
SILICONE O-RING 4.5x6.6mm (RED)
15105
1
NITRO STAR G3.0 ENGINE with PULLSTART
15162
1
COMPOSITE ROTARY CARBURETOR COMPLETE (F2/6.5mm)
30011
1
SILICONE EXHAUST TUBE
50474
1
SILICONE TUBE 2x5x300mm
72001
2
PILOT SHAFT 4x30mm
72102
2
SHOCK CAP 12xM13x0.8mm (PURPLE/ GROOVED)
AIR CLEANER 30mm ( , )
72140
1
LINKAGE SET ( , )
72144
1
BRAKE CAM SHAFT/PLATE SET ( , )
72148
1
ARM BRACE SET ( , )
72157
1
1
MAIN CHASSIS
73942
75106
20
BODY CLIP (6mm/BLACK)
76817
1
SPUR GEAR 47T (2 SPEED)
85031
1
SHOCK TOWER/BUMPER SET (NITRO 3)
85032
1
BODY POST/LINK SET (NITRO 3)
85036
1
GEARBOX SET (NITRO 3)
85037
1
REAR HUB SET (2 DEGREE/1 DEGREE)
85038
1
FRONT UPRIGHT SET (8 DEGREE/10 DEGREE)
85039
1
SERVO HORN (for 50/50 THROW)
85055
1
UPPER DECK SET
85056
2
SUSPENSION ARM SET (190mm WIDTH)
85057
1
TUNED PIPE SET
SPRINT GEAR DIFF BEVEL GEARS (13T, 10T) ( , , , )
86014
1
86022
1
COLLET 6x10mm
86076
1
PILOT NUT 1/4-28x8.5mm (BLACK)
86094
6
SCREW SHAFT M4x2.5x12mm (BLACK)
86126
2
STANDOFF 7x25mm
HEAVY-DUTY FINAL GEAR SET (P1x36T/P1x14T) ( , )
86329
1
86331
1
HEAVY-DUTY CUP JOINT 5x10x18mm (D CUT/SILVER)
86332
2
HEAVY-DUTY DIFF SHAFT (SILVER)
86333
2
HEAVY-DUTY GEAR SHAFT 5x37mm (SILVER)
CLUTCH SHOE/SPRING SET ( , )
86869
1
86891
1
FLYWHEEL 7x33x7mm
86931
1
ENGINE MOUNT
86933
2
SHOCK SPRING 13.8x27x1.5mm 8.5COILS (METALLIC RED)
86934
1
CUP JOINT 6x10x50mm
86935
1
CENTER DRIVE SHAFT 6x14mm
86936
1
CENTER DRIVE SHAFT 6x112mm
86937
1
DRIVE SHAFT 6x47mm
86938
1
EXHAUST HEADER
86939
1
EXHAUST PIPE 8x75mm
86940
1
SPUR GEAR HUB
Option Parts List
En
Parts # Qty
Description
17209
1
TOYOTA TRUENO AE86 BODY (190mm)
17218
1
NISSAN 350Z GREDDY TWIN TURBO BODY (190mm)
DE TOMASO PANTERA BODY (F200mm/R210mm/WB255mm)
17502
1
17508
1
1965 FORD SHELBY GT-350 BODY (200mm/WB255mm)
17519
1
1966 FORD MUSTANG GT BODY (200mm)
17523
1
PAGANI ZONDA F CLEAR BODY (200mm)
17524
1
VERTEX RIDGE TOYOTA SOARER BODY (200mm)
2012
1
HUMP BATTERY PACK FOR RECEIVER (6V 1200mAh/Ni-MH)
3574
2
RAYS GRAM LIGHTS 57S-PRO 26mm CHROME (0mm OFF SET)
3710
2
MESH WHEEL 26mm WHITE (1mm OFFSET)
3711
2
MESH WHEEL 26mm BLACK (1mm OFFSET)
3712
2
MESH WHEEL 26mm CHROME (1mm OFFSET)
3713
2
MESH WHEEL 26mm GRAY (1mm OFFSET)
3715
2
MESH WHEEL 26mm WHITE (3mm OFFSET)
3716
2
MESH WHEEL 26mm BLACK (3mm OFFSET)
3717
2
MESH WHEEL 26mm CHROME (3mm OFFSET)
3718
2
MESH WHEEL 26mm GRAY (3mm OFFSET)
3770
2
10 SPOKE MOTOR SPORT WHEEL 26mm WHITE
3771
2
10 SPOKE MOTOR SPORT WHEEL 26mm BLACK
3772
2
10 SPOKE MOTOR SPORT WHEEL 26mm CHROME
3827
2
DEEP RIM 5 SPOKE WHEEL 26mm CHROME
3835
2
TE37 WHEEL 26mm WHITE (0mm OFFSET)
Liste de pièces / Liste des pièces optionnelles
パーツリスト / オプションパーツリスト
Parts # Qty Description
86941
2
FLANGE SHAFT 3x30mm (BLACK)
86942
2
FLANGE SHAFT 3x45mm (SILVER)
86955
1
PRO SILICONE SHOCK OIL 30wt (60cc)
87021
1
FUEL TANK with PRIMER (75cc)
87023
3
DIFF ADJUSTMENT SPRING 3x14x0.5mm
87057
1
SILICONE EXHAUST COUPLING 12X36mm (PURPLE)
93312
2
TURNBUCKLE 4-40x24mm
93317
2
TURNBUCKLE 4-40x34mm
BALL M2x3.8x4.5mm
A249
4
A280
4
FLANGE SHAFT SET 3x25mm/A284 3x30mm
A281
4
FLANGE SHAFT SET 3x36mm/A282 3x42mm
SERVO SAVER SET ( , )
A396
1
DIFF CASE ( , )
A431
1
A471
2
SHOCK PARTS SET
A540
2
HPI SPORTS SHOCK BODY (45-56mm)
A556
2
AXLE 5x32mm (FRONT)
A557
2
AXLE 5x38mm (REAR)
A783
4
BALL 4.7x14mm (PURPLE ANODIZED)
A838
4
FLANGE PIPE 3x4.5x5.5mm
A875
5
EXHAUST GASKET
A993
1
HEAVY DUTY CLUTCH BELL 18 TOOTH (1M)
B021
2
BALL BEARING 5x10x4mm
2
BALL BEARING 5x11x4mm
B022
B030
2
BALL BEARING 10x15x4mm
Z125
14
BALL CUP
Z136
4
BALL END 4-40 (BLACK)
Z150
1
ANTENNA PIPE SET
Z162
1
HEAVY WEIGHT GREASE (#100000/GEAR DIFF)
Z164
1
HEAVY DUTY GREASE
Z224
10
WASHER M3x8mm
Z238
4
C CLIP 13mm
Z242
20
E CLIP E2mm
Z264
10
PIN 2x10mm SILVER
Z282
4
STEP SCREW M3x14mm
Z509
6
BUTTON HEAD SCREW M3x30mm
Z516
6
BINDER HEAD SCREW M3x10mm
Z517
10
BINDER HEAD SCREW M3x8mm
Z518
6
BINDER HEAD SCREW M3x12mm
Z526
6
FLAT HEAD SCREW M3x8mm
Z527
6
FLAT HEAD SCREW M3x10mm
Z542
12
CAP HEAD SCREW M3x8mm
Z543
6
CAP HEAD SCREW M3x10mm
Z561
6
TP. FLANGED SCREW M3x10mm
Z567
10
TP. BINDER HEAD SCREW M3x10mm
Z568
10
TP. BINDER HEAD SCREW M3x12mm
Z569
10
TP. BINDER HEAD SCREW M3x15mm
Z578
10
TP. FLAT HEAD SCREW M3x12mm
Z581
10
TP. FLAT HEAD SCREW M3x18mm
Z653
6
NUT M3
Z662
4
LOCK NUT M2
Z684
4
FLANGED LOCK NUT M4
Z694
10
WASHER M5x10x0.5mm SILVER
Z699
2
WASHER 7x12x0.8mm BLACK
Z721
4
SET SCREW M4x4mm
Parts # Qty Description
3836
2
TE37 WHEEL 26mm BLACK (0mm OFFSET)
3837
2
TE37 WHEEL 26mm CHROME (0mm OFFSET)
TE37 WHEEL 26mm BRONZE (0mm OFFSET)
3838
2
3840
2
TE37 WHEEL 26mm WHITE (3mm OFFSET)
3841
2
TE37 WHEEL 26mm BLACK (3mm OFFSET)
3842
2
TE37 WHEEL 26mm CHROME (3mm OFFSET)
3843
2
"TE37 WHEEL 26mm BRONZE (3mm OFFSET)
3845
2
TE37 WHEEL 26mm WHITE (6mm OFFSET)
3846
2
TE37 WHEEL 26mm BLACK (6mm OFFSET)
3848
2
TE37 WHEEL 26mm BRONZE (6mm OFFSET)
4405
2
T-GRIP TIRE 26mm (2pcs)
4406
2
T-DRIFT TIRE 26mm
4415
2
PRO BELTED SLICK TIRE 26mm (2pcs)
4435
2
RACING SLICK BELTED TIRE 26mm (B15-40)
4490
2
X-PATTERN RADIAL TIRE 26mm PRO COMPOUND
4495
2
X-PATTERN RADIAL BELTED TIRE 26mm PRO COMP
4496
2
X-PATTERN RADIAL BELTED TIRE TQ COMPOUND 26mm
4675
2
INNER FOAM 26mm (SOFT)
4676
2
INNER FOAM 26mm (MEDIUM)
4678
2
PRO MOLDED INNER FOAM 26mm (SOFT/ROUNDED)
4679
2
PRO MOLDED INNER FOAM 26mm (HARD/ROUNDED)
4704
2
MOUNTED SUPER DRIFT TIRE (A TYPE) ON TE37 WHEEL CH
