ETO2
WIRING
Terminal Colour code
PE, N, L
1, 2
3, 4
5, 6
7, 8
11, 12 brown/green
13, 14 grey/purple
15, 16 yellow/white
17, 18 grey/purple
19, 20 yellow/white
21, 22
23, 24
25, 26
Wiring
Supply voltage, 120-240 V AC 50/60 Hz
Alarm relay (potential free) max. 5 A
Output relay 1, 16 A (potential free),
Heating cable 1 (zone 1) / Primary pump
Output relay 2, 16 A (potential free),
Heating cable 2 (zone 2) / Secondary pump
Output relay 3, 16 A (potential free),
Heating cable 3
Heating element 1+2, ETOG and ETOR
Temperature sensor 1, ETOG
Moisture sensor 1, ETOG / ETOR
Temperature sensor 2, ETOG
Moisture sensor 2, ETOG / ETOR
3/4-way mixing valve, 0-10 V
3/4-way mixing valve, 24 V AC
Supply voltage 24 V AC for 3/4-way mixing valve
English
7
