Battery Mounting; Lipo Battery Charging - Carson Lynx Betriebsanleitung

i. Battery Mounting
Attention:
• Do not mix old and new batteries/rechargeable batteries.
• Do not mix different types of batteries.
• Do not charge non-rechargeable batteries.
GB
1
Open the cover.
4
Return the battery box back to
the compartment.
j. LiPo Battery Charging
The helicopter is equipped with a LiPo battery
7.4 V/ 650 mAh LiPo battery
Connect the battery to the balance charger and wall charger. The two
LED lights are red whilst charging and turn green when charging is
finished.
34 CARSON FPV Spy Beast Lynx • 50 050 7053
2
Take out the battery box.
5
Fasten the screw.
3
According to the correct polarities, install
8 x AAA batteries.
6
Ready!
