Affinity Instruction for Use - EN
Guidance and manufacturer's declaration - electromagnetic emissions
The AFFINITY is intended for use in the electromagnetic environment specified below. The customer or the
user of the AFFINITY should assure that it is used in such an environment.
Emissions Test
RF emissions
CISPR 11
RF emissions
CISPR 11
Harmonic emissions
IEC 61000-3-2
Voltage fluctuations /
flicker emissions
IEC 61000-3-3
Recommended separation distances between portable and mobile RF communications equipment and the
AFFINITY.
The AFFINITY is intended for use in an electromagnetic environment in which radiated RF disturbances are
controlled. The customer or the user of the AFFINITY can help prevent electromagnetic interferences by
maintaining a minimum distance between portable and mobile RF communications equipment (transmitters)
and the AFFINITY as recommended below, according to the maximum output power of the communications
equipment.
Rated Maximum Separation distance according to frequency of transmitter
output power of [m]
transmitter 150 kHz to 80 MHz
[W]
d = 1.17
0.01 0.12
0.1 0.37
1 1.17
10 3.70
100 11.70
For transmitters rated at a maximum output power not listed above, the recommended separation distance d
in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is
the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
Note 1 At 80 MHz and 800 MHZ, the higher frequency range applies.
Note 2 These guidelines may not apply to all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
Guidance and Manufacturer's Declaration - Electromagnetic Immunity
The AFFINITY is intended for use in the electromagnetic environment specified below. The customer or the
user of the AFFINITY should assure that it is used in such an environment.
Immunity Test IEC 60601 Test
Level
Electrostatic +6 kV contact
Discharge (ESD)
+8 kV air
IEC 61000-4-2
Electrical fast +2 kV for power supply
transient/burst lines
IEC61000-4-4 +1 kV for input/output
lines
Surge +1 kV differential mode
Compliance Electromagnetic environment - guidance
Group 1 The AFFINITY uses RF energy only for its internal
function.
Therefore, its RF emissions are very low and are not
likely to cause any interference in nearby electronic
equipment.
Class B The AFFINITY is suitable for use in all commercial,
industrial, business, and residential environments.
Complies
Class A Category
Complies
Compliance
+6 kV contact
+8 kV air
+2 kV for power supply
lines
+1 kV for input/output
lines
+1 kV differential mode
80 MHz to 800 MHz
d = 1.17
0.12
0.37
1.17
3.70
11.70
Electromagnetic
Environment-Guidance
Floors should be wood, concrete
or ceramic tile. If floors are
covered with synthetic material,
the relative humidity should be
greater than 30%.
Mains power quality should be
that of a typical commercial or
residential environment.
Mains power quality should be
that of a typical commercial or
Page 68
800 MHz to 2.5 GHz
d = 2.23
0.23
0.74
2.33
7.37
23.30
