1. UNLOADING

The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device on a special wooden platform, secured with cardboard angle sections and foil.

2. PROPERTIES OF THE DEVICE

2.1. Purpose

"Kasia GRZ" display cabinet is used to display and short-lasting storage of previously prepared hot dishes in GN con-
tainers before serving them. These devices constitute basic elements of equipment in mass feeding facilities. Scope of
water temperature regulation in tank chamber ranges between +30ºC/+90ºC.

2.2. Description of the device

KASIA GRZ" is a water bain-marie. GN containers are placed over the water bath heated with electrical heaters placed
directly in bain-marie tank. The display cabinet is equipped with mechanical temperature regulator, fl uid level regulator and
front glass hot air inlet. Depending on the type and purpose of the display cabinet, "Kasia GRZ" devices are available in
two versions, with (Z) or without the reservoir. Depending on its purpose, the display cabinet is manufactured in stationary
and moving version. Our devices are made according to modern technologies and have all certifi cates required by law.
Contents
1. UNLOADING
2. PROPERTIES OF THE DEVICE
2.1. Purpose
2.2. Description of the device
2.3. Technical data
3. PREPARING THE DEVICE FOR EXPLOITATION
3.1. Requirements concerning the place of installation
3.2. Connection and actuation
4. EXPLOITATION
4.1. Water level in bain-marie tank
4.2. Temperature regulation
5. MAINTENANCE
5.1. Cleaning and maintenance
6. SERVICE
6.1. Fault identifi cation and repair
6.2. Service
This sign signifi es information of particular meaning for user security and for proper device
exploitation.
8
User manual Kasia GRZ
KASIA GRZ
List of Figures
8 Fig.1 Construction of „Kasia GRZ" device
8 Fig.2 Construction of „Kasia Z GRZ" device with reservoir
8 Fig.3 Layout of cross-bars under GN containers
8 Fig.4 Layout of GN containers
10 Fig.5 Removing the wooden platform
10 Fig.6 Wheel system, moving system
10 Fig.7 Assembly of glass elements and aluminium profi les
10 Fig.8 Control panel
12 Fig.9 Bain-marie tank
12 Fig.10 Front glass disassembly
13 Fig.11 Changing the fl uorescent lamp
13 Fig.12 Data plate
13
List of tables
14
14
Table 1. Number of cross-bars under GN containers
14
Table 2. Technical data
en
en
9
9
9
10
10
10
11
11
12
13
13
14
9
