PRODUCT DESCRIPTION

HOW DOES THE JAGA CLIMA BEAM WORK?
Working principle
Jaga Clima Beam cools in the most fective way:
The rising hot air is drawn in by the DBE fans. The air that has been cooled via the heat exchanger
is blown out and then slowly drops evenly into the room. With the "dry cooling" principle there is no
energy loss due to the formation of condensation.
Jaga Clima Beam is also suitable for heating.
the Low-H O heat exchanger is equipped with fans in order to optimally transfer the heat or cooling.
2
The built-in Jaga Dynamic Product Controller (JDPC) makes it possible to control the DBE units.
Control is via a 0-10V signal through a building management system (BMS) or a room thermostat.
OVERVIEW
12V
56
Low-H 0 heat-exchanger
2
(T20 of T21)
DBE-rail
JDPC
Power: IN: 100-240V
Waterproof connector
OUT: 12V
Mounting plate with control unit
