Jetter JX3-BN-EC Betriebsanleitung Seite 48

Jetter AG
JX3-BN-EC Betriebsanleitung
Sub-
Beschreibung/
Index in-
Name
dex
0x8000 Parameter Module:JX3-THI2-RTD
:0x0 SubIndex 000
:0x1 Diagnostics..State
:0x2 Channel 1.Common.Command
:0x3 Channel 1.Common.ForceVal
:0x4 Channel 1.Configuration.PotResist
:0x5 Channel 1.Configuration.Average
:0x6 Channel 1.Configuration.LimitMin
:0x7 Channel 1.Configuration.LimitMax
:0x8 Channel 1.Configuration.TotalMin
:0x9 Channel 1.Configuration.TotalMax
:0xa Channel 2.Common.Command
:0xb Channel 2.Common.ForceVal
:0xc Channel 2.Configuration.PotResist
:0xd Channel 2.Configuration.Average
:0xe Channel 2.Configuration.LimitMin
:0xf Channel 2.Configuration.LimitMax
:0x10 Channel 2.Configuration.TotalMin
:0x11 Channel 2.Configuration.TotalMax
0xA000 Status Module:JX3-THI2-RTD
:0x0 SubIndex 000
:0x1 Channel 1.Common.State
:0x2 Channel 1.Common.Value in Fahrenheit
:0x3 Channel 1.Common.2-wire measuring ac-
tive
:0x4 Channel 1.Common.3-wire measuring ac-
tive
:0x5 Channel 1.Common.4-wire measuring ac-
tive
:0x6 Channel 1.Common.10 ms Conversion
active (0=100ms)
:0x7 Channel 1.Common.Value Valid
:0x8 Channel 1.Common.Channel is calibrated BOOL
:0x9 Channel 1.Common.Forceval is shown
:0xa Channel 1.Common.PT100 active
(0=PT1000)
:0xb Channel 1.Common.Temperatur active
(0= Resistance)
:0xc Channel 1.Common.Calibration active
:0xd Channel 1.Common.Potentiometer-mode
active
:0xe Channel 1.Common.Channel 1 active
Programmierung | 7
Typ Zugriff
USINT ro
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
UDINT rw
USINT ro
UDINT ro
BOOL ro
BOOL ro
BOOL ro
BOOL ro
BOOL ro
BOOL ro
ro
BOOL ro
BOOL ro
BOOL ro
BOOL ro
BOOL ro
BOOL ro
48 / 88
