SATA HRS Betriebsanleitung Seite 488

Operating Instructions for SATA HRS
US
Art.
No.
[4-4] 11494
[4-5] 133983
[4-6] 3426 *
[4-7] 12591 *
[4-8]
157305
[4-9]
8300
[4-10]
68890 *
[4-11] 15438 ** Paint needle packing
[4-12] 41806
[4-13] 8318 *
[4-14] 8359
[4-15] 11510
[4-16] 38034
[4-17] 11502
[4-18]
11445 *
[4-19]
11544 *
[4-20]
53082 *
[4-21] 11437 *
[4-22] 10322
161158
* Available in repair kit 161158 only
15.2. HRS with plastic pressure cup
Art.
No.
[5-1]
208
[5-2]
182 *
[5-3]
11460 *
[5-4]
11494
[5-5] 133983
[5-6] 3426 *
[5-7] 12591 *
488
Description
Cam rod, complete with O-ring
Air connection piece, 1/4"(male thread)
Safety washer
Bracket bolt
Trigger
HRS suction pipe
Valve, complete
1 liter aluminum pressure cup
Sealing ring
Quick connect coupling
Mixing cap
Paint needle for flow control, complete with
needle bush
Paint needle, complete with needle bush
Pressure spring for air piston
Compression spring for paint needle
O-ring 0.5" x 0.1", made of Perbunan
End screw
Guide bushing
HRS repair kit
Description
Material flow control nut
Counter nut
Air piston
Cam rod, complete with O-ring
Air connection piece, 1/4"(male thread)
Safety washer
Bracket bolt
** Available as service unit
Quan-
tity
1 set
1 ea.
1 ea.
1 ea.
1 ea.
1 ea.
1 set
1 set
1 ea.
1 ea.
1 ea.
1 ea.
1 set
1 set
1 ea.
1 ea.
1 ea.
1 ea.
1 ea.
1 set
Quan-
tity
1 ea.
1 ea.
1 ea.
1 set
1 ea.
1 ea.
1 ea.
