Attention!
Physical damage from incorrect cleaning
The pressurized cup spray gun can be damaged if immersed in solvent
or cleaning agent or if cleaned in an ultrasonic cleaning machine.
→ Do not place the pressurized cup spray gun in solvent or cleaning
agent.
→ Do not clean the pressurized cup spray gun in an ultrasonic cleaning
machine.
■ Unscrew the pressurized cup [1-4] / [1-7] / [1-13]; in doing so, the pres-
surized cup spray gun is also vented at the cup thread.
■ Fill the pressurized cup with a suitable cleaning agent and screw onto
the pressurized cup spray gun.
■ Shake the pressurized cup spray gun thoroughly.
■ Spray the cleaning agent out of the pressurized cup spray gun through
the connected wand at the quick coupling [1-15] until clean and wipe
the outside with a cloth soaked in cleaning agent or with a cleaning
brush.
■ Blow the pressurized cup spray gun dry.
11.3. Clean the check valve
If the check valve [1-18] doesn't work, it must be removed and cleaned.
■ Remove the check valve [1-18] (see chapter 10.2).
■ Clean the spring [2-2] and ball [2-3] thoroughly with a suitable cleaning
agent.
■ Coat the spring and ball with SATA high performance grease (Art. No.
48173).
■ Mount the check valve (see chapter 10.2).
11.4. Clean the inlet valve
■ Unscrew the pressurized cup [1-4] / [1-7] / [1-13]; in doing so, the pres-
surized cup spray gun is also vented at the cup thread.
■ Unscrew the inlet valve [3-8] out of the gun body [3-9].
■ Clean the inlet valve with a cloth soaked in cleaning agent or with a
cleaning brush.
■ Blow the inlet valve dry.
■ Screw the inlet valve into the gun body.
