Safety Instructions; Initial Setup - swissflex uni 20_75RF basic Bedienungsanleitung

Health and comfort
Welcome to the world of Swissflex!
Your Swissflex uni 20_75RF is a Swiss quality pro-
duct. If you follow the simple operating and safety
instructions, it will function to your complete sa-
tisfaction for many years. In addition to its many
other advantages, your uni 20_75RF offers an un-
disturbed sleep environment. All electrical con-
nections between the mains plug and the bed are
virtually free of mains voltage (below 0.5 watts)
thanks to EcoTec.
Safety instructions
CAUTION! The uni 20_75RF and accessories must
be protected from rain and other moisture to pre-
vent causing a fire hazard or the risk of electric
shock. In case of spillages on an accessor y, the
mains cable (12) must be disconnected from the
power outlet and checked by your Swissflex stok-
kist.
When installing the slat base, ensure that the
head, back and foot sections are not obstructed
by furniture.
Ensure that the mains supply is disconnected be-
fore any assembly or disassembly work is carried
out on the slat base or the bed frame.
Do not connect any devices to the user socket (17)
that could endanger persons or damage objects
when the socket is turned on by remote control,
in particular electrical tools such as saws, drills
and similar (risk of injury) or portable heating de-
vices (risk of fire).
Never place the mains cable between the user
socket (17) and the bed in such a way that the
cable insulation could be damaged by sharp
edges or twists. Never feed the cable through the
adjustment mechanism.
In the case of damage to cables to the control
housing or to the user socket (17), do not adjust
the bed to a seated position. Remove the mains
plug from the socket and inform your stockist.
Never open the user socket housing (17) to which
the cables are connected. If you interfere with any
electrical part of the user socket (17), the gua-
rantee entitlements will no longer apply.
Handle the uni 20_75RF and accessories with
care; do not disassemble or modify them, do not
allow children to play with them and prevent frail
individuals from using the product without super-
vision.
The product may not be used with a medical de-
vice or be installed in a medical device.
The product may not be used in an environment in
which flammable or explosive gases or vapours
GB
(e.g. anaesthetics) are likely to occur.
The product may not be used to raise and lower
loads.
Only use spare par ts that have been produced
or approved by Swissflex. Only these parts gua-
rantee adequate safety.
Initial setup
Place the batteries into the radio remote control
Remove the cover from the battery compartment
(10) on the back of the radio remote control. Place
3 A A A-batteries (11) into the compartment, pa-
ying attention to the +/- markings. Close the com-
partment cover again. The maximum range of the
radio remote control is 15 metres.
Teaching-in the remote control (already taught-
in in the factory)
1. Remove the remote control's battery cover on
the back of the device.
2. Insert / check the batteries (3x A A A).
3. Activate the teach-in button on the motor con-
trol (press 2x). It flashes once after successful
activation.
4. A small red button is located above the batte-
ries in the battery compartment.
5. Press the button; a blue LED will start flas-
hing.
6. Hold the button down until the blue LED is per-
manently illuminated; this means that pairing
has been completed.
Pocket lamp
The pocket lamp is illuminated when the „Pocket
lamp" button (1) is held down. The light turns off
when the button is released. This button is illumi-
nated (blue) while the pocket lamp is in use.
Lock buttons
To lock the buttons, hold down the „Lock buttons"
button (9) for five seconds. Once the button lock
has been activated, all buttons (except for the
mains outlet (8), the pocket lamp (1) and the but-
ton lock (9)) flash (blue) twice.
All buttons flash twice (white) when a disabled
button is pushed. The lock is disabled by holding
down the „Lock buttons" button (9) for five se-
conds. All buttons flash twice (blue) if this was
Operating instructions
13
