You can find the latest update of this user manual in the Internet under: Vous pouvez trouvez la dernière version de ce mode d'emploi dans l'Internet sous: Vd. puede encontrar la versión más reciente de este manual en el Internet bajo: www.eurolite.de 2/18 70064150_V_1_0.DOC...
- sich die letzte Version der Anleitung im Internet herunter laden 1. EINFÜHRUNG Wir freuen uns, dass Sie sich für einen EUROLITE AT-DIMM 3 DMX entschieden haben. Wenn Sie nachfolgende Hinweise beachten, sind wir sicher, dass Sie lange Zeit Freude an Ihrem Kauf haben werden.
Seite 4
Das Gerät darf nicht in Betrieb genommen werden, nachdem es von einem kalten in einen warmen Raum gebracht wurde. Das dabei entstehende Kondenswasser kann unter Umständen Ihr Gerät zerstören. Lassen Sie das Gerät solange uneingeschaltet, bis es Zimmertemperatur erreicht hat! Bitte überprüfen Sie vor der ersten Inbetriebnahme, ob kein offensichtlicher Transportschaden vorliegt.
3. BESTIMMUNGSGEMÄSSE VERWENDUNG Bei diesem Gerät handelt es sich um einen elektronischen Dimmer, mit dem sich andere Geräte wie Scheinwerfer in Diskotheken, auf Bühnen etc. dimmen lassen. Dieses Produkt ist für den Anschluss an 230 V, 50 Hz Wechselspannung zugelassen und wurde ausschließlich zur Verwendung in Innenräumen konzipiert.
4.2 Frontplatte 1. Kanal-Sicherung F2.5A 250V 2. DMX-Eingangsbuchse für RJ45 Stecker 3. DMX-Ausgangsbuchse für RJ45 Stecker 4. DOWN-Taste Drücken Sie diese Taste, um den Display-Wert zu senken. 5. UP-Taste Drücken Sie diese Taste, um den Display-Wert zu erhöhen. 6. ESC-Taste Drücken Sie diese Taste, um in den 1.
Das Display zeigt dann wieder A, gefolgt von der DMX Adresse, an. Durch Drücken der UP-/DOWN-Tasten können Sie durch die 7 verschiedenen Hauptmenü-Punkte des AT-DIMM 3 DMX navigieren. Wählen Sie einen der Punkte aus, indem Sie die ENTER-Taste drücken. 7/18...
Die Hauptmenü-Punkte sind: 1. DMX-Adresse A001 (1-510) 2. Kanalwert 1 (0-255) 3. Kanalwert 2 (0-255) 4. Kanalwert 3 (0-255) 5. PRES (1-32), Speichern Sie bis zu 32 Kanalwerte ab. 6. DEMO; Demoprogramm 7. SETU; Setup Menü 1. EINSTELLEN DER DMX-ADRESSE Die voreingestellte Adresse ab Werk ist A001.
Seite 9
Display Display Helligkeit Reset Auf Werkeinstellungen zurücksetzen Version Versionsnummer der Software auf dem Display Preheat (Vorwärmen) Wählen Sie den Menüpunkt „PrEH“ aus und bestätigen Sie mit ENTER. Die erste Stelle des Displays zeigt den Kanal an. Die Ziffern nach dem Punkt stehen für den Preheat-Wert. Drücken sie UP bzw.
- download the latest version of the user manual from the Internet 1. INTRODUCTION Thank you for having chosen a EUROLITE AT-DIMM 3 DMX. If you follow the instructions given in this manual, we are sure that you will enjoy this device for a long period of time.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The arising condensation water might damage your device. Leave the device switched off until it has reached room temperature. Please make sure that there are no obvious transport damages. Should you notice any damages on the A/C connection cable or on the casing, do not take the device into operation and immediately consult your local dealer.
Do not shake the device. Avoid brute force when installing or operating the device. When choosing the installation-spot, please make sure that the device is not exposed to extreme heat, moisture or dust. There should not be any cables lying around. You endanger your own and the safety of others! This device must never be operated or stockpiled in sourroundings where splash water, rain, moisture or fog may harm the device.
4.2 Front panel 1. Fuse F2.5A 250V 2. DMX-input socket For RJ45 plug 3. DMX-output socket For RJ45 plug 4. Down button Press this button to decrease the value on the display. 5. Up button Press this button to increase the value on the display. 6.
30 mA. 6. OPERATION Start your AT-DIMM 3 DMX. The controller type is indicated for 5 seconds on the display. If EROR or SYNC is indicated, the device is defective. In this case, please contact your dealer.
Main Menu: 1. DMX address A001 (1-510) 2. Channel 1 (0-255) 3. Channel 2 (0-255) 4. Channel 3 (0-255) 5. PRES (1-32), save up to 32 presets. 6. DEMO; Demo program 7. SETU; Setup menu 1. SETTING THE DMX ADDRESS The default setting is A001.
Seite 17
Preheat Browse the setup menu and select PrEH with the ENTER button. The first figure on the display indicates the channel (1-3). The other numbers represent the preheat value. Use UP and DOWN to select a different channel and press ENTER. The channel starts blinking and you can set a preheat value with UP/DOWN.
300 x 185 x 95 mm Weight: 3 kg Accessory: EUROLITE ATP-512 3-channel controller No. 70063600 EUROLITE RGB-300 MR-16 GU-10 mini spot No. 50850360 Black plastic electric plug No. 3023610A Safety plug, smash proof, black No. 30236215 Power-cord with open ends, 3x0.75, 2mNo.
