Replacing the electronics, see fold-out page IV
1. Disassemble plastic plate, see Fig. [30a].
Disassemble metal plate, see Fig. [30b].
2. Detach lift rod (P) from lever (V3), see Fig. [35a] or [35b].
3. Remove bracket with servo motor (V).
4. Disconnect plug connections from electronic module (C) to
extension cable (L) and to servo motor (V), see Fig. [36].
5. Pull old electronic module (C) out of bracket (Q) and replace
electronic module, see Fig. [37].
6. Calibrate servo motor, see Calibrating the servo motor.
Fault/ cause/ remedy
Fault
Indicator lamp in electronics
flashing continuously after
calibration
No flushing after pressing the
button
Water flowing continuously
Undesired flushing
Flow volume too low
Flow volume too high
7. Install servo motor, see Installing the servo motor.
8. Register radio transmitter, see Registering a radio
transmitter.
9. Install actuation plate, see Installing the plate.
Replacement parts, see fold-out page I (* = special
accessory).
Care
For directions on the care of this fitting, refer to the
accompanying Care Instructions.
Cause
• Calibration incorrect
• Obstacle during calibration
• Servo motor defective
• Water supply interrupted
• Radio transmitter not registered
• Electronics defective (indicator lamp
does not flash when button is pressed)
• Servo motor defective (no rotation)
• Plug-in connector without contact or not
connected
• Radio transmitter too far away
• No voltage
• Transformer defective
• Battery in radio transmitter discharged
• Actuation plate is not suitable
• Waste valve not closing
• Adjacent radio transmitter unintentionally
registered
• Flow volume set too low
• Outlet valve does not lift fully out
• Servo motor defective (incomplete
rotation)
• Residual flow rate too high
• Flow rate in cistern too low
• Flow volume set too high
Remedy
- Perform calibration again, ensuring there
is no obstacle in the adjustment range of
the servo motor, see Calibrating the
servo motor
- Replace servo motor, see Maintenance
Replacing the servo motor
- Open isolating valve in cistern
- Register radio transmitter, see
Registering a radio transmitter
- Replace electronics, see Maintenance
Replacing the wall plate with electronics
- Replace servo motor, see Maintenance
Replacing the servo motor
- Attach plug-in connector
- Install radio transmitter closer to cistern
- Switch on voltage supply
- Replace transformer, see Maintenance
Replacing the transformer
- Replace battery, see Replacing the
battery, instruction: 96.485.XXX
- Replace actuation plate
- Adjust servo motor position, see
Calibrating the servo motor, or waste
valve defective (repair, replace), see
Cistern instructions
- Delete all radio transmitters, see Deleting
a radio transmitter, and re-register the
correct radio transmitters, see
Registering a radio transmitter
- Adjust flow volume, see Setting the flow
volume
- Adjust servo motor position, see
Calibrating the servo motor
- Replace servo motor, see Maintenance
Replacing the servo motor
- Push residual flow slider downwards, see
Setting the flow volume for manual
actuation
- Turn float of filler valve further upwards
- Adjust flow volume, see Setting the flow
volume
