1. Description

The EX-1187HMVS is a plug & play high-speed USB 3.1 (Gen1) metal hub for 7 USB
devices. The EX-1187HMVS provides 7 ports for USB devices and 1 uplink port for PC.
It supports all USB connections from 1.1 to 3.1. All ports can fix with screw lock. Via a
external power supply it is possible to provide a maximum of 1,5A on each USB port.
The EX-1187HMVS design fully utilize the Genesys chipset, which represents the latest
in SuperSpeed USB interface technology. It uses data transfer rates up to 5Gbit/s. It
provides a secure and very high data transfer on each single port. The EX-1187HMVS
support the Self Powered and Bus Powered mode. In addition the EX-1187HMVS is
equipped with an 15KV ESD surge protection. The EX-1187HMVS is IP30 compliant.
The DIN-Rail Kit is included in the extent of delivery for installation in a 19" Rack. The
DIN-Rail kit will be tightened with four screwed on the back of the EX-1187HMVS.
Features:
•
Compatible for USB 1.1, 2.0, 3.0 & 3.1
•
Up to 5Gbit/s
•
All Operating Systems are supported
•
All ports are Screw Lock
•
15KV ESD Surge Protection
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1187HMVS to your PC, you should first check the contents
of the delivery:
•
EX-1187HMVS
•
USB 3.1 (Gen1) Cable (screw lock)
•
DIN-Rail Kit
•
Manual
