Features
8 System Status LEDs
9 Power LED
10 Redundant PS LED
11 Thermal Fault LED
12 Fan Fault LED
English
Steady Green
Steady Orange
Steady Green
Steady Orange
Steady Green
Steady Orange
Off
Steady Orange
Off
Steady Orange
Off
Compex 24 Port 10/100 Mbps plus 2 Port Gigabit
Copper SNMP Managed Switch
SGX3226
Status and Indication
Normal Operation.
POST is running Self-diagnostic after
reset/power up.
Power supply is working in normal
condition.
•
Power supply is faulty.
•
Power supply fault occurs.
Primary power supply is working and RPS
is in standby mode.
Primary power supply is faulty and RPS is
in working condition.
When the primary power resume its
electrical supply, RPS LED will still
remains Steady Orange unless you reboot
your switch, then RPS LED will turn to
Steady Green.
Both primary power supply and RPS turned
off.
Temperature inside the chassis is too high
for normal operation.
Normal condition.
Ventilation fans have problems. Thermal
fault may result if condition persists.
Ventilation fans are operating in good
condition.
