4. Panel Description

Features
1 24 RJ45 10/100 Mbps
Ports
2 Console Port
3 2 Open Expansion
Module Slots
4 Primary Power Socket
5 Redundant Power
Socket
6 Reset Button
7 Mute Button
4
Use UTP/STP network cables to connect
•
10 Base-T
•
100 Base-TX
All ports will detect and automatically switch to uplink mode
when connected to a switch/hub.
A serial 9 Pin (DB9) socket is connected to PC COM Port for
monitoring the switch.
•
Comes with 1000 Base-T module
•
Option for 1000 Base-SX and 100 Base-FX modules
Flexible power input (range 100 V-250 V AC)
Additional Power Socket (Optional). With this RPS, Compex
SGX3226 is still able to operate even when the Primary
Power Supply is down. Flexible power input (range 100 V-
250 V AC)
Note:
Please connect AC main power to the Primary Power Supply
first followed by the RPS.
By pushing the reset button once,
•
The switch will clear all previous temporary error
•
POST will activate self-diagnostic program to check any
error.
•
Switch would be re-configured with settings stored in
non-volatile flash memory.
To toggle ON or OFF Switch of the Alarm Buzzer
Compex 24 Port 10/100 Mbps plus 2 Port Gigabit
Copper SNMP Managed Switch
SGX3226
