Figure 1
+
15V
1
3
Cable length
5 to 50 m
50 to 100m
Connecting of the dry contact (gate automation) or electric strike plate to the intercom panel
Cable length
0 to 25m
2
EN
2
4
m c o n . s o m o h y t m w . w w
100m max
Connection from the intercom panel to the monitor
Section to use
0.75mm
2
1.5mm
2
Section to use
0.75mm
2
COLOUR VIDEO INTERCOM
25m
max
25m
max
