− The indicator light located on the front of the product flashes 5 times before it gets into PIR auto working mode.
NOTE: For some settings, user needs to press "MENU" to save and exit the configuration after pressing "OK" to confirm (Camera ID, Delay, Time
Lapse, Timer, Password).
7.3. How to enable camera to send photos?
− Camera will automatically enter MMS and 3G setups when the SIM card is inserted.
− If "SIM Auto setup failed, enter setups manually" pops up on the screen, please switch "SIM setup" from "Auto setup" to "Manual
setup" mode, then enter MMS and 3G setups in "Manual Setup".
− Enter recipient(s) phone number(s) and email account(s).
− If you'd prefer to allow camera to consume only 3G data flow of your SIM card, please remember to enter receiving email accounts, and
delete MMS setups from Menu.
NOTE: If you'd like to use your own SMTP server for sending photos, please switch "Default" to "Manual" mode in the SMTP" setting for
further configurations.
− Without SMTP configured, camera will send photos to both phone number(s) and email(s) by consuming MMS charge.

8. Operation list

8.1. Photo/video playback on the LCD screen
− Slide the switch to the "SETUP" position.
− Press " " to enter playback, then press "⊳" and " " for selection.
− Press "OK" to play photo/video.
− Press " " again to exit.
8.2.

Delete files

− Slide the switch to the "SETUP" position.
− Press " " to enter playback, then press "⊳" and " " for selection.
− Press the "MENU" button then select "Delete" and press "OK".
− Select "One" (delete the selected photo/video) or "All" (delete all photos/videos) then press "OK".
− If your selected "One", "Delete This File?" will appear on the screen, select "Yes" or "No" then press "OK".
− If you selected "All", "Delete all files?" will appear on the screen, select "Yes" or "No" then press "OK".
− Press "MENU" to exit.
8.3.

Format SD card

− Slide the switch to the "SETUP" position.
− Press " " to enter playback.
− Press the "MENU" button then select "Format" and press "OK".
− Select "Yes" or "No". If you selected "Yes", "Are you really sure?" will appear on the screen, select "Yes" or "No" then press "OK".
− Press "MENU" to exit.
8.4.

Auto power off

In "SETUP" mode, the camera will automatically power off if you don't press the keypad for 3 minutes. Slide the switch to "OFF" then back to
"SETUP'" if you want to do some further configuration.
NOTE: Camera stays in "SETUP" mode if camera is in Menu configuration pages.
8.5.

Operation menu

Slide the switch to the "SETUP" position then press "MENU" once to enter camera setting menu.
You can navigate the setting interface by pressing "⊳", " ", " " or " ". Press "OK" for selection, "MENU" to exit to previous page, and
"MENU" to switch alpha/digits/symbols.
NOTE: For some settings, user needs to press "Menu" to save and exit the configuration after pressing "OK" to confirm (Camera ID, Delay, Time
Lapse, Timer, Password).
Cam PIR
Camera ID
Camera Mode
LED
Photo resolution
Night Mode
MENU Exit
PIE1023 - Indice A
3G Other
OFF
All
5MP
OK Set
Cam PIR
Multi shot
Video resolution
Video Length
MENU
Exit
3G Other
1 photo
HD
05
OK Set
