Compex One Schnellstartanleitung Seite 3

Description of stimulator
EN
A
On/Off button
B
Sockets for 4 stimulation cables
C
Stimulation cables
Channel 1 = blue Channel 2 = green Channel 3 = yellow Channel 4 = red
D
+/- buttons for 4 stimulation channels
E
Socket for the charger (slide the red cover to the right to free the charger connector)
F
Battery compartment
G
Belt clip socket
1. Connecting the Cables
2. Selecting Language, Contrast and Volume
B
Use the channel 1 +/- button to choose the language
you wish to use.
C
Use the channel 2 +/- button to adjust the contrast
of the screen.
D
Use the channel 3 +/- button to adjust the volume.
E
Use the channel 4 +/- button to adjust the backlight.
On: Backlight always on.
Off: Backlight always off.
Auto: Backlight activated whenever a button is pressed.
A
Use the On/Off button to confirm and save your choices. The settings will be
applied immediately.
A
E
1 2 3
B
+
-
D
4
C
1
G
F
ONE
A B C D E
