Programming the speed controller

Mode 2 (powered model): no brake or soft-
start, but with: temperature monitoring and
low-voltage speed reduction, stall protection and
speed limiting.
Mode 3 (helicopter mode): no brake, tem-
perature monitoring, stall protection or speed
limiting, but with: soft-start and speed regulation.
Mode 4 (competition): no soft start, temperatu-
re monitoring, low voltage detection, stall protec-
tion or speed limiting, but with: brake (hard).
Once the system has been used for the first
time, the commutation timing is set to "auto-
matic".
DESCRIPTION OF SET-UP PROCEDURE
The set-up procedure is initiated when the con-
troller is switched on and detects a signal which
can be interpreted as full-throttle (pulse width
longer than 1.5 ms) for more than five seconds.
· Switch on the transmitter, move throttle stick
to full-throttle
· Switch on receiver and controller
· After about five seconds you hear a rising
triple tone
· If you are using Li-Po cells, wait a further five
seconds until you hear a second triple tone
· Pull the stick right back (motor stopped)
· Wait until you hear the audible signal corres-
ponding to the mode you wish to use; i.e.
if you wish to program mode 3, wait for the
triple tone etc.
· Move the stick back to full-throttle and wait for
confirmation
· If you do not wish to set a separate neutral
position, disconnect the battery, and the job is
done.
· Otherwise move the stick to the neutral pos-
ition (windmill point) and wait for confirmation,
then disconnect the battery - job done.
RECOMMENDED MOTORS
Order No. 7700
Order No. 7702
Order No. 7703
Order No. 7704
Order No. 7705
Order No. 7706
Order No. 7707
Order No. 7708
Order No. 6530
Order No. 6531
Order No. 7709
Order No. 7710
Order No. 7711

SPECIFICATION

Order No.
Compact Control 10
Operating voltage:
Cell count, Ni-MH / Ni-CD:
Continuous current:
Start-up current, 10 sec.:
EMF brake:
Over-temperature guard:
Power-on pulse suppression: yes
Pulse frequency:
BEC receiver power supply:
Low-voltage cut-off:
Dimensions in mm approx.:
Weight incl. cables approx.:
Programming the speed controller
COMPACT 160
COMPACT 170
COMPACT 170
COMPACT 235
COMPACT 235
COMPACT 260
COMPACT 260
COMPACT 300
INLINE 330
INLINE 400
COMPACT 300
COMPACT 320
COMPACT 320
2873
7.2 ... 12 V
6 - 10
10 A
20 A
yes
no
8 kHz
5 V / 2 A peak
1 - 4 servos
yes
37 x 20 x 7
13 g
7.2 V
7.2 V
7.2 V
7.2 V
9.6 V
7.2 V
8.4 V
7.2 V
7.2 V
8.4 V
9.6 V
7.2 V
8.4 V
9
