1. IMPORTANT REMARK

Congratulations! You are the owner of a carefully designed and manufactured equipment.
We thank you for the confidence you've placed in our company when choosing our IW6 loudspeaker
for wall/ceiling mounting.
In order to get the optimum operation and efficiency from this unit, it is VERY IMPORTANT
- before you plug anything - to read this manual very carefully and bear in mind all considerations
specified within it. We strongly recommend that its maintenance be carried out by our Authorized
Technical services.

2. WARNINGS

Never use this unit in the proximity of water. Do not expose the unit to water splashing, nor
place liquid containers on top of it.
Avoid placing the unit next to heat sources such as spotlights or heaters.
Use only the accessories specified by the manufacturer, employing the correct accessories
for each application.

3. INTRODUCTION

ECLER's IW6 unit, a loudspeaker for wall/ceiling mounting, uses carefully selected
components integrated in a design which allows an easy handling and a fast installation. They also
provide excellent sound quality for high and low frequencies thanks to our infinite speaker philosophy
and to top-performance high frequency transducer.
Because we have included a transformer, the unit are extremely versatile and are easy to
use both in applications with low impedance and in applications running at 100V/70V. All you have to
do is shift the position of the built-in selector.
The transducer used to play low and medium frequencies are made of polypropylene,
giving them maximum, long-term stability and protecting them from environmental factors like heat
and humidity.
Technical specifications:

2 way speaker system for wall/ceiling mounting

6.5" polypropylene woofer

25mm tweeter

Power: 40W RMS@8

Sensitivity (1W/1m): 87 dB SPL

Built-in transformer

Dimensions: 236x344x67mm

Installation system: Six revolving fasteners
Note: If you use the speaker in 70V installations, the power for the 100V position will be half the
amount shown on the switch. When used in 50V installations, it will be a fourth of the amount.
The IW6 model comes with a protective grill that can be removed with a hook included in
the package. Be careful not to damage the speaker when removing the grill.
