4.3 Channel selection
The camera is factory-set to channel 1. If this channel
is interference-free and if no second camera is oper -
ated at the same time, it is not necessary to pay atten-
tion to the following information.
The wireless transmission is made in the 2.4 GHz
range which has been divided into four channels for the
series of units AV-4xxSET. Two wireless cameras can
be operated at the same time, e. g. to monitor two
rooms. For this purpose always one channel between
the two transmission channels must remain free, so
that they do not interfere with each other. The following
channel combinations are possible:
channel 1 and channel 3 or
channel 1 and channel 4 or
channel 2 and channel 4
1) To adjust another transmitting channel, slide the
sunshield (4) backwards and screw off the front
housing sleeve (5). Select the channel with the DIP
switches (1):
1
2
Channel 1 Channel 2
2.414 GHz 2.432 GHz
Channel 3 Channel 4
2.450 GHz 2.468 GHz
When screwing together subsequently, pay atten-
tion to the tight fit of the sealing ring so that the
camera housing is weatherproof again.
2) Select the operating mode of the receiver with the
DIP switch M/L (14):
Position M = manual channel selection: Adjust the
desired transmission channel with the button (18).
Position L = automatic channel selection for re-
ceiving the signals of several cameras: Every 4 sec -
onds, the receiver will switch between the channels
of which the DIP switches (14) are set to ON; the
other channels will be skipped. The LEDs (17) of the
channels used will light up. The LED of the channel
received at the moment will flash.
