3.1 Conformity and Approval
GB
Herewith, MONACOR INTERNATIONAL de clare that
the set of units AV-430SET is in accordance with the
basic re quirements and the other relevant regulations
of the directive 1995/5/EC. The declaration of conform-
ity can be found in the Internet via the MONACOR
INTER NATIONAL home page (www.monacor.com).
The set of units is licence-free and generally
approved for operation in EU and EFTA countries.
4

Operation

4.1 Placing the camera and receiver
Practical experience has shown that an optimum
reception is achieved when placing the units at a height
of minimum 1.5 m to 2 m above the ground. Prior to the
final mounting, a trial run is recommended as the trans-
mission quality can substantially be changed by dis-
plac ing the camera and the receiver by a few centi-
metres only.
If required, the camera can be mounted at a suit-
able place with the supplied support (8). After releasing
the corresponding nuts, the camera can be inclined
and moved.
12
4.2 Connections
1) Connect the jack A/V (13) to the monitor via the
adapter cable provided:
connect the red phono plug to the audio input,
connect the yellow phono plug to the video input
2) Connect one of the supplied antennas (15) to the
SMA jack (16). Alternatively, with insufficient receiv-
ing qual ity, it is also possible to use a 2.4 GHz direc-
tional antenna with corresponding gain, e. g. an
antenna of the DX series from MONACOR.
3) Connect the plug of the supplied 8 V power supply
unit (11) to the jack DC8V (12) and the power sup-
ply unit to a mains socket (230 V~/50 Hz).
4) Connect the second antenna (7) to the SMA jack (6)
of the camera.
5) Connect the plug (10) of the supplied 12 V power
supply unit to the inline jack (9) of the camera and
the power supply unit to a mains socket (230 V~/
50 Hz). Thus, the units are in operation. After use,
disconnect the power supply units from the sockets
for switching them off. In case of outdoor mounting,
the low voltage inline jack (9) and the low voltage
plug (10) must be made weather-resistant.
The two power supply units for camera and
receiver are provided with different plugs to prevent
confusion which may result in damage to the units.
