Note: The image may differ from the actual product.
Typical Network Topology
For the EAP
■
Internet
Router
A computer running the EAP Controller software, which can be in the same or
different subnet with the EAPs, is used to centrally manage the EAPs.
You can get the EAP Controller software from our website http://www.tp-link.com.
For the CAP (FIT Mode)
■
Internet
Router
The wireless controller can be in the same or different subnet with the CAPs. And
the management host is used to log in to the wireless controller to centrally manage
the CAPs.
Switch
PoE Switch
6
EAP
EAP
EAP Controller
Controller Host
CAP
CAP
Wireless Controller
Management Host
English
Clients
Clients
