TP-Link CAP300 Installationsanleitung Seite 11

Option2 ： Wall Mounting
■
1
Place the mounting bracket in the position you
require. Mark three positions for the screw
holes. Drill three 6mm (in diameter) holes at
the marked positions.
2
Insert the plastic wall anchors into the 6mm
holes. Align the bracket to the plastic wall
anchors and drive the self-tapping screws into
the anchors through the bracket.
3
Align the mounting tabs on the back of
the Access Point with the four slots of the
mounting bracket. Push and slide the Access
Point downward until it locks into place.
4
Connect the antennas to the Access Point.
8
English
