BAcK PAnEl AcTIVE SPEAkER:
lD SAT62A
MAIn lEVEl
1
Adjusts the speakers volume
2
PoWER MoDE
Switches to contineous on (ON) or to standby mode (AUTO). In position AUTO the amplifier is turned to ON
by receiving a signal. After several minutes without any signal the amplifier turns again to standby mode.
3
PoWER lED
Lights up RED if device is in STANDBY mode. Lights up GREEN if device is turned ON.
InPUT XlR / 6.3 mm jack
4
Balanced Line Input for XLR connectors and 6.3 mm jacks.
lInE DIREcT oUTPUT
5
Direct, balanced Line Ouput for XLR connectors. Should be used to loop the signal to another LD SAT62A.
PoWER SWITcH
6
ON / OFF switch.
PoWER connEcTIon SEAT
7
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if mains power
is disconnected and only by fuse of same type and rating (T1A 250V AC). If fuse blows repeatedly please
contact authorized personel for servicing.
8
oVERloAD lED
Lights up when speaker is overloaded. Reduce volume immediately.
