P3 Modulated TENS Program
100 mA
Maximum Intensity:
Zero net DC component
2 x 8 μC
Maximum charge per pulse:
Low Voltage Indication
• Indicator Threshold: 2.3 Volts (typical)
• Shutdown Voltage: 1.95 Volts (typical)
• These voltages may be tested under NO load condition.

Fuse Characteristics

6V, 1.5 A, Resettable, breaking capacity 3A

Physical Characteristics

• Size (without belt clip): 5.4" x 2.6" x 1.2"
• Weight (with batteries and belt clip): ~ 6 ounces
• Operational Temperature: 10°C to 40°C
• Humidity (maximum): 75% RH
EN 60601-1 Classification
• Type BF Applied Part
• Internally powered only
• Protection against ingress of particles and liquids: IP22
• Continuous operation
• Not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide.
Phoenix User's Manual
P4 Edema Program
100 mA
Maximum Intensity:
266 μA, independent of the set intensity as
DC component:
long as the set intensity is above 4 mA.
7.2 μC for the positive pulse and 6
Maximum charge per pulse:
μC for the negative pulse
33
