To self-test for any of the above, perform the following steps:
Place new batteries in the device.
1.
Verify the device is off.
2.
Insert one new lead wire into two new electrodes.
3.
Place the new electrodes on your forearm as shown in Figure A.
4.
Insert the lead wire in Channel 1.
5.
Turn your device on.
6.
Select program P3 (TENS). This is a continuous treatment program.
7.
Slowly increase the amplitude (intensity) until you can feel it. If you do not get any sensation, lower the amplitude
8.
(intensity) to zero and rotate the lead wire 90 degrees. Slowly increase the amplitude (intensity).
If there is no sensation, call the Repair Department.
9.
If sensation is felt, even if weak, the device is working properly. You may need to reposition the electrodes or contact
10.
your clinician.
Repeat Steps 1 through 10 for Channel 2.
11.

9. Device Maintenance

9.1 Service

Please contact DJO Global if you need assistance setting up, using or maintaining the Phoenix system or to report any
unexpected operations or events. Please also contact DJO Global for clinical questions or if any component of the Phoenix
System is not functioning properly or requires servicing. You can find the different contact possibilities under
www.DJOGlobal.eu.

9.2 Cleaning and Calibration

Clean using a damp cloth or soft cloth and an alcohol based, solvent-free cleaning product. Use only a minimum amount of
liquid when cleaning the Empi Phoenix device. Allow the Empi Phoenix device to completely dry before use.
Do not sterilize the stimulator. Do not immerse in liquids.
Your stimulator does not require calibration. Each Empi Phoenix stimulator is tested prior to distribution. Its characteristics do
not vary under normal conditions.
26
Figure A
Phoenix User's Manual
