7. Operating Instructions

You are strongly advised to carefully read the Safety Information in Section 4 at the beginning of this manual prior to using
your stimulator.
Sudden temperature changes can cause condensation to build up inside the stimulator. To prevent this,
Precaution:
allow it to reach room temperature before use.

7.1 Description of the Device

G
A
B
C
E
D
User Interface LCD
A.
ON/OFF (Pause) button
B.
Program Selection (Increase) button
C.
D. Program Selection (Decrease) button
Channel 1 Intensity Increase/Decrease button
E.
Channel 2 Intensity Increase/Decrease button
F.
Channel 1 output connector
G.
Channel 2 output connector
H.
I. Remote switch input connector (hand switch is an optional accessory)
Belt Clip (removable)
J.
Battery door to access the battery compartment. A label describing the programs is affixed to the battery door.
K.
Phoenix User's Manual
H
J
F
K
17
