3. Part Names

a
b
i
a Zoom & Focus
b Lens hood
c Light sensor for IR LEDs
d IR LEDs
e Dome base
f Mount holes (x3) for dome base
g OSD control joy stick
c
d
Bubble
j k
Dome base
e
f
l
h Video Sub-output
i Clear bubble
j Ring cover fixing screws (x3)
k Ring cover
l Pipe hole with blind cover
m Dome base fixing screw taps (x3)
n Surface mount holes (x3)
8
g
h
Mount base
m
n
