PS3 SET UP :
1] Connect the HDMI between the PS3 console and TV/Monitor.
2] Connect the RED/WHITE connectors on the RCA to Audio cable
3] Connect the the wireless transmitter into an available
4] Connect the audio cable into the wireless transmitter.
5] Turn on your PS3 console.
6] Turn your Headset ON by pressing the Power Button. Pairing with the
7] Make sure that microphone mute is OFF.
8] Go to Settings > Accessory Settings > Audio Device Settings
9] Go to Settings > Sound Settings > Audio Output Settings,
7
EX6UNI-wireless-manual-book.indb 7
WITH HDMI (OPTION B)
into the Audio OUT RED/WHITE sockets on your TV/Monitor.
USB port on the front of your PS3 console.
wireless transmitter should happen automatically. However, if pairing is
unsuccessful, please refer to the Pairing section in 'Getting Started'.
and select EX-06 Headset for both the Input and Output. You
will be able to hear yourself talking into the microphone through
the headset earcups. Set the desired volume level.
choose Audio Input Connector/ Scart / AV Multi.
HDMI CABLE
(NOT SUPPLIED)
TV/MONITOR
HDMI INPUT
PLEASE NOTE: Your TV/Monitor will need to have Audio Out (RED/WHITE) sockets.
Most, but not all TVs/Monitors have RED/WHITE Audio IN and YELLOW Video IN sockets
but not all TV's, and even fewer monitors have RED/WHITE Audio OUT sockets.
HDMI OUTPUT
01
02
TV / MONITOR
AUDIO OUT
CONNECT INTO
THE FRONT
OF PS3
03
04
