5. CONFIGURATION/EclerCOMM Manager SOFTWARE

The ALMA24/ALMAcard device can be configured only through the Windows© EclerCOMM
Manager application, since the ALMA24/ALMAcard has no local controls.
The EclerCOMM Manager application is available for free download from the Ecler web site.

5.1. Installation and connection with ALMA24/ALMAcard

Once you have downloaded the software, it is recommended that you first connect the USB
cable supplied with the equipment between a computer's USB port and the ALMA device USB port. After
this, the installation is performed by running the downloaded installer file and following the steps
displayed on screen.
Once installed, run the EclerCOMM Manager application to open its graphical interface, where
you need to select, in the first place, the type of device you want to connect, in this case
ALMA24/ALMAcard. This is done by accessing the Device -> Select menu:
Then by clicking on the Connect with device button, the communication can be established with
the hardware device, after choosing the synchronization option (SEND to send the current configuration
to the hardware device or GET to load the hardware device's current settings in the application):
The F2 key allows you to rename your hardware device:
