Connecting AC Power

The electrical rating for the PanelView 1400 terminal is shown below.
Terminal Type
PV1400
The PanelView 1400 terminal is an IEC 1131-2 Equipment Class I device and
requires you to connect the
ATTENTION:
!
safe use when installed in a suitably rated NEMA Type 12, 13, 4X
(indoor use only), IP54 or IP65 enclosure.
ATTENTION
!
wiring connections have been made. Failure to do so may result in
electrical shock.
PanelView 1400 Terminals
Supply Voltage
85 to 264V ac,
47 to 63 Hz
(Protective Earth) terminal to an earth conductor.
The PanelView 1400 terminal is designed for
: Do not apply power to the terminal until all
Power Consumption
200 VA maximum
11
