DESIGNATIoN of pARTS

1
1 Battery compartment cover
2 Elastomere protection
3 Push button
4 Eye cup (foldable)
5 Eyelet for neck strap
04
2 3 4
10 9
5 6
8
6 Eyepiece
7 Tripod mount 1/4"-2OUNC
8 Type label
9 Objective – transmitter
10 Objective – Day optics & receiver
5
7
