Lightmaxx LED NANO PAR Bedienungsanleitung Seite 23

Specifications:
Model
Output signal
DMX channel
Power supply
Power consumption
Light source
Irradiance
Lens optic
Beam angle
Average LED lifetime
Control panel
Function
Dimmer
Protection class
Dimensions
Weight
Troubleshooting:
The following overview serves as an aid for quick troubleshooting. If you are unsure, contact the
manufacturer, the dealer or the corresponding specialist personnel. Never open the device on
your own!
Symptom
No function
No reaction in DMX mode
If the specified corrections have not led to success, please contact our service staff. The contact
details can be found at www.musicstore.de
LED NANO PAR
DMX 512 international standard
8
AC 100-240 V // 50/60 Hz
15 W
12 x 1 W LED (3x red/3x green/3x blue/3x white)
1020 Lux @ 1m (RGBW 100%)
15 mm Edison EDOL 25°
25° MFL
60.000 h
LED Display + 4 menu keys
Sound 2 Light, Auto, Master/Slave, DMX-512
0-100%
IP20
150 x 115 x 140 mm
0,4 Kg
Troubleshooting
Check the mains connection and the fuse
Check the cable connections
Check your DMX address setting
If available, try an alternative DMX controller
ENGLISH
