General Description

Overview

Figure 1
1
18
1 Carrying strap
2 Two-piece suction tube
3 Additional grip
4 Carrying strap bracket
5 On/off switch
6 Flow control (ELS 2400 TE only)
7 Housing grip
8 Vents
9 Cable holder
48
2
17 16 15
3 4 5 6
10 Mains cable
11 Lawn vacuum motor compartment
12 Operation mode switch
13 Leaf bag holder
14 Leaf bag
15 Guide rollers
16 Tube extension clip (ELS 2400 TE only)
17 Blower opening
18 Suction inlet
7
8
9
10
11
12
13
14
