DC2412-UPSD | DC2412-UPS-LDD | UPSIC-1205D | UPSIC-2403D
11 Integrated μExtension module
The μExtension module PSZ-1063, integrated as a standard feature, is an intelligent
add-on module with a variety of features.

11.1 Data Monitoring

Continuous operational data collection allows „real-time data monitoring". The data is
continuously collected via I²C interface of UPSIC and DC2412 UPS devices and stored
in the μExtension module. The implemented RS232 interface on the module allows to
forward data to the host, which ensures easy system implement.

11.2 Integrated reboot function

Another core feature of the module is the reboot function, which enables the system to
automatically reboot as soon as the input voltage returns during shutdown or at a later
time. The startup function of the mainboard can be easily activated via BIOS when input
voltage is present.

11.3 Controlled release of output voltage

It is possible to control output enable by a safety function. In this case, output enable
does not take place until the supercapacitors reach 90 % of their capacity. A safe shut-
down of the system is thus always guaranteed.

11.4 Software independent operation

The UPS can also be operated without software on the host. The configuration of the time
values is easily adjustable via DIP switch and the module generates the shutdown signal.
Of couse, options for software-controlled time settings and shutdown via UPS Control
Center remain in effect.
