Description of the connection box RV-SWITCH-30

At the front: (see E)
1 Bush connecting cable.
Plug in the plug until it audibly engages.
2 Bush connecting lead, 4-pole bush.
The supply line consists of three branch lines:
Red = voltage supply 12 V to 24 V (max. 30 V)
Black = earth cable
Green = Control input (S/BY) for the automatic switching-on of the system.
Connect the cable to the positive line of the reversing light.
Rear (see E)
3 Sockets for the cameras 1 and 2, 6-pole sockets.
4 Switch 1 and 2 for the mirror-image representation of camera 1 and/or 2.
(see F)
1POWER Operation On/Off
2 MODE
3 VR √ ®
4 MUTE
5AUTO PIC
6RECALLDisplay of the current volume/video channel
7 MENU
8 PRO † π
06.11.2003 12:20 Uhr

Remote control

Selection of the video source (input 1 or 2)
Volume and setting within a function
Audio muting - switches the tone on/off
Fetches the 4 image presetting
Menu selection button, calls up the different menus
Button for the selection of the functions within a menu
